HG Nonwoven Macinery is one well-known non woven fabric machine manufacturer in China, which specializes in manufacturing all types of PP/PET/PLA spun bond and melt blown non woven fabric making machine such as S/SS/SSS/SMS/SMMS/SSMMS include turn-key project service.

Product Description

What is Non woven fabric making machine?

Spunbond nonwoven fabric making machine is a full production line of producing PP non-woven fabrics, which use polypropylene granules as raw material, adopts the latest spunbond spinning technology to produce endless filaments.
The spunbond nonwoven machine is an integrated, continuous production line that transforms polymer granules like polypropylene directly into a fabric web. As the core equipment for manufacturing Spunbond Nonwoven Fabric (S), it is one of the most common types of nonwoven fabric making machines.
The single spinning head (S) nonwoven machine is characterized by its simplicity, cost-effectiveness, and high efficiency in producing a wide range of standard, single-layer spunbond nonwoven fabrics. It is the ideal solution for manufacturers targeting large-volume, price-sensitive markets.

⚙️ HG-1600S / 2400S / 3200S PP Spunbond Series

This series can produce fabrics with a maximum width of 1600mm / 2400mm / 3200mm and a weight range of 10-200 GSM.

🚀 Typical Applications

  • Agriculture: Crop covers, weed control fabric, plant protection.
  • Geotextiles: Soil stabilization, erosion control, drainage layers.
  • Packaging: Wrapping, shopping bags, durable goods covers.
  • Furniture & Bedding: Spring insulators, quilt backing, mattress.
  • Home Improvement: Housewrap, roofing base.
Spunbond Nonwoven Machine

Key Characteristics of Spunbond Nonwoven Machine

  • Simplicity with lower Investment Risk: Ideal for small to medium-sized enterprises.
  • Lower Capital Cost: Entry-point technology for many manufacturers.
  • Easier Operation and Maintenance: Features a single spinning beam and drawing unit.
  • High Production Efficiency: Designed for continuous, high-speed production and uptime.
  • Good Uniformity: Excellent cross-direction (CD) and machine-direction (MD) uniformity.
NONWOVEN MACHINERY

Integrated Production Process Zones

1. Raw Material Feeding & Extrusion System
PP chips & additives are melted in the extruder using heated barrels and a rotating screw.
2. Melt Pump & Spinning Beam
Provides precise pressure to push molten polymer through the spinneret to form continuous filaments.
3. Filament Quenching & Drawing System
Cool air solidifies filaments, which are then stretched by high-speed air jets to increase strength.
4. Web Formation & Suction Unit
Filaments are randomly scattered onto a moving belt, assisted by a suction unit for a uniform web.
5. Thermal Bonding (Calender)
The web passes through heated rollers, fusing filaments together into a strong, flat fabric.
6. Winding & Slitter
Finished fabric is wound into jumbo rolls and trimmed or slit to required widths.

Why Choose Our Technology

nonwoven fabric machine
Our technology enables customers to produce nonwoven fabrics economically, reliably, and sustainably. We offer specialized support including:
  • Market analysis and feasibility reports.
  • One-stop project engineering solutions from A to Z.
  • 2 years of door-to-door engineering after-sale service.
  • Advanced 5th Generation spunbond spinning technology.
Production Line
Machine Shipping

Technical Specifications

Model HG-1600S HG-2400S HG-3200S
Production Capacity (kgs) 40,000 60,000 100,000
Power Consumption (kW) 250kW 350kW 450kW
Machine Width (mm) 1600mm 2400mm 3200mm
Max. Speed (m/min) 200m 200m 200m
Thickness (GSM) 10-200g/m² 10-200g/m² 10-200g/m²
Dimension (L*W*H) 20*8*11m 20*10*11m 20*12*12m
Machine Detail
HG nonwoven machine

Frequently Asked Questions

What materials can be used with this machine?
The machine primarily uses polypropylene (PP) granules. It can also be configured for other polymers like PET or PLA depending on specific requirements.
What is the thickness range of the nonwoven fabric produced?
Our S-series machines are capable of producing nonwoven fabrics ranging from 10 GSM to 200 GSM (grams per square meter).
Is the machine suitable for beginners in the nonwoven industry?
Yes, the single beam (S) machine is an ideal entry-level solution due to its simpler operation, lower maintenance requirements, and more affordable capital investment.
Do you provide installation and training?
We offer one-stop project engineering which includes installation, onsite commissioning, and training for your operators to ensure smooth production.
What is the 5th Generation spinning technology?
It is an advanced spinning technology that integrates overseas design concepts to optimize power consumption, fabric uniformity, and overall production efficiency.
How many countries do you export to?
Our equipment is currently running reliably in more than 20 countries and regions worldwide, with over 300 production lines in operation.
