China PP Spunbond Nonwoven Fabric Machine Factory, Factories

1 / 2

China PP Spunbond Nonwoven Fabric Machine Factory, Factories

PP spunbond nonwoven fabric machine is suitable for PP spunbond non woven fabric making. It is a process that includes extrusion of polymers to form continuous filaments, which will be later conditioned, stretched and deposited onto a conveyor belt to create the web, then will be embossed and winded into spunbond nonwoven fabric rolls.

Send Inquiry

Product Description

Spunbond Nonwoven Fabric Making Machine Technical Specification

Model	1600mm Model	2400mm Model	3200mm Model
Technology	Spun bond non woven making
Spinning beam	S/SS/SSS
Raw material	Polypropylene chip
Output(ton)	5/9/14ton	7/13/18ton	10/16/24ton
Speed (m/min)	200/350/400 m/min
GSM range(g/sqm)	10-200 g/sqm
Filament Denier	1.6-2.0 denier

Customerization can be acceptable.

Production Line Overview

PP Raw Material

➔

Extrusion Machine

➔

Melt Filtration Machine

➔

Melt Pump

➔

Spinning Machine

➔

Fiber Forming Machine

➔

Thermal Bond

➔

Nonwoven Fabric Rolls

The Advantage of Spunbond Nonwoven Fabric Making Machines

High accurate raw material blender for raw material and additives;
High capacity extrusion machine with good screw and barrel;
High performance melt filtration system;
High Speed with high accurate melt pump;
Latest melt flow design and spinning system;
Well-know PLC control system and Siemens motors;
Smart operation program and monitoring system;
Imported Enka / Kasen spinneret and meltblown die;

Selecting the Ideal Non woven Fabric Machine Line for the Right Application

Please select which kind of nonwoven business you want to start. With our deep expertise across diverse sectors like packaging, medical, hygiene, and agriculture, we will guide and help you in technical support to choose one most suitable line to start your business easily. Our solutions are crafted to save you time, reduce costs, and overcome operational challenges with efficiency.

Packaging

Nonwoven fabric used in packaging industry is the most popular like shopping bag, flower wrappers, laundry bag, and garment bag, and etc.

Medical

Spunbond and meltblown nonwoven fabric will be the best choice in usage of medical field like face mask, surgical gowns, disposable mattress and etc.

Hygiene

Spunbond nonwoven fabric used in hygiene will be required softer and breathable in hygiene filed like baby or adult diaper and feminine products etc.

Agriculture

Nonwoven fabric roll used in agriculture field like crop cover, plant protect, and seed blankets, usually require the function of anti-UV to protect plant.

Frequently Asked Questions (FAQ)

What models of Spunbond Nonwoven Fabric Making Machines are available?

The technical specifications offer three primary models based on width: 1600mm Model, 2400mm Model, and 3200mm Model. Customization option is also acceptable.

What raw material is used for the production line?

The standard raw material required for the nonwoven fabric making process is Polypropylene (PP) chips.

What is the output capacity and speed of these machines?

Depending on the specific configuration (S/SS/SSS) and width, the output capacity ranges from 5 tons up to 24 tons per day. The machine run speed ranges between 200 to 400 meters per minute.

What applications are these spunbond nonwoven fabrics suitable for?

The produced fabrics are ideal for four main industries: Packaging (shopping bags), Medical (face masks and surgical gowns), Hygiene (diapers and feminine care products), and Agriculture (crop and plant protection covers with anti-UV capabilities).

What are the core technical advantages of this machinery?

Key technical highlights include a highly accurate raw material blender, high capacity extrusion machine, advanced melt filtration system, high precision melt pumps, smart PLC program with Siemens motors, and premium imported spinneret components.
